JD14 engine
The JD14 (13.6L/827-cu in.) engine from John Deere Power Systems has the power to handle heavy draft disks and rippers, hydraulically demanding air seeders and planters, and large transport loads like grain carts and slurry wagons. With a durable design and heavy-duty components, you can depend either on the Final Tier 4 (FT4)/Stage V compliant JD14 engine or a Tier 3/Stage IIIA compliant JD14 engine, standard in the 291 to 471 engine kW (390 to 640 engine hp) 9 Series Tractors.
We developed the JD14 from the ground up, starting with stronger castings and bearings and tougher internal components, all designed to meet the high demands of field operations. We replaced the fuel injectors with a high-pressure common rail (HPCR) fuel system and eliminated the diesel particulate filter (DPF) to boost fuel efficiency and lower operation and maintenance costs. Integrated coolant and oil passages, along with a new belt-driven water pump, eliminate potential leak points and allow for a less-crowded engine compartment, improving serviceability and reducing debris accumulation.
In redesigning the engine, we also gave it:
- Hydraulic valve lash adjusters to maintain valve-lash settings during engine operation, reduce valve train noise and wear, and allow for greater fuel efficiency.
- A hydraulic fan drive for improved cooling capacity with no required maintenance.
- A new integrated wiring harness design featuring a modular layout for reduced vibration, greater reliability, and easier service and diagnostics.
- A rear gear train that integrates fully into the cast-iron block, reducing engine noise and improving the durability of the crankshaft damper.
- Combination sensors where possible, meaning fewer sensors, connectors, and wires.
- A powerful engine brake that allows operators to use the engine to control tractor and implement speeds while transporting or traveling downhill, reducing wear on the drivetrain brake components.
13.5L (824-cu in.) engine compared to JD14 (13.6L/827-cu in.) engine
Feature |
13.5L (824-cu in.) engine |
JD14 (13.6L/827-cu in.) engine |
Fuel delivery |
Electronic unit injectors (EUI) |
HPCR |
Aftertreatment |
Two canisters |
One canister |
Valve lash adjustment |
Manual |
Automatic |
Engine brake |
Not available |
Available above 402.7 kW (540 hp) |
Wire harness |
Single harness |
Three short harnesses |
Water pump |
Gear driven |
Belt driven |
Gear train |
Front mounted |
Rear mounted |
Fan drive |
Vari-Cool™ system (FT4) or fixed fan (Tier 2) |
Hydraulically driven (FT4) or fixed fan (Tier 3) |
NOTE: The PowerTech™ 13.6L (827-cu in.) engine has been renamed the JD14.
