Tillage | 2430 Chisel Plow

TruSet™ Tillage technology

The 2430 Chisel Plow is designed for precise, accurate depth control. Precise depth control is very important for conservation of moisture, fertilizer placement, and soil management. Soil layers of differing soil type vary across farms and even across fields. The ability to adjust for these conditions is extremely important to producers today.

TruSet and single-point depth control both come as standard equipment. Both provide accurate depth control to best utilize available tractor horsepower.

With TruSet, these adjustments can be done on the move, increasing productivity and making the day go easier for operators. TruSet provides accurate and precise depth control by the use of individual wheel sensors and electronic circuitry to perform tasks of leveling and depth measurements unprecedented in the industry until now. Accurate depth is displayed to the nearest 2.5 mm (1/10 in.).

The floating hitch, frame strength of the Tube-Thru-Tube manufacturing, and the wheel package placement allow the 2430 to offer unmatched consistency of depth (front-to-back and side-to-side). Fuel can be saved, soil can be mixed and shattered, and accurate depth can be maintained. This represents true soil management for the producer.

TruSet Side-to-Side

TruSet Side-to-Side gives producers the same level of individual section control that was available with AccuDepth™ hydraulics. However, there are differences in how the two systems are hydraulically plumbed.

The AccuDepth hydraulics required a correction valve on every frame section since the hydraulics were plumbed in parallel. The TruSet system is plumbed into a single-point (series) system.

The series hydraulics give producers the option of controlling depth with just the single-point depth control valve or individually controlling each frame section with a correction valve mounted at the base of each depth control cylinder on the wings. The individual section control with TruSet Side-to-Side is an upgrade to the base TruSet Tillage system.

TruSet Side-to-Side is controlled by five sensors compared to one sensor with the base TruSet Tillage system. With the five-sensor control, the implement can make depth control adjustments via sensor feedback to independently adjust wing section depth.

TruSet Side-to-Side eliminates the need to rephase the depth control cylinders after several rounds in the field. However, it does require another step when calibrating.

Documentation and prescription

With integrated TruSet Tillage technology, operators can incorporate documentation and prescription functionality into their tillage operations. The tillage documentation feature will give producers the ability to capture and analyze the pass for additional coverage of the crop production cycle. Prescription functionality provides producers the capability to ensure their tillage operations are executed correctly, optimizing their investment in preparing for the next crop.

Operators can document data for the depth of their sweeps along with rolling basket down pressure. By creating an as-applied map based off of global positioning system (GPS) data for the job performed by each functional area on the implement, TruSet enables producers to document their tillage passes ro later review and analyze data for future agronomic decisions.

Additionally, the TELUS Agronomy Prescription Creator company, a connected partner tool through the John Deere Operations Center, enables producers to create prescriptions for each functional area. Data from previous yields, soil surveys, or freehand drawing tools can be used to create prescriptions that will command the implement to the desired depth and pressure settings for optimum agronomic results.

TELUS Agronomy Prescription Creator is a trademark of TELUS Agriculture and Consumer Goods

Functionality by control option

	Single-point	TruSet	TruSet Side-to-Side
One adjustment to change implement depth	X	X	X
Mechanical adjustment option	X	X	X
In-cab adjustment option	---	X	X
In-cab individual section leveling	---	---	X
Tillage documentation and prescription	---	X	X

Radial tires

Radial tires reduce compaction points while operating in the field and minimize downtime caused by tire failures both in the field and during transportation. Radial mainframe tires now come in base equipment and can be an option on the wings. With a wider tire plate and lower inflation pressure, radial tires have a larger contact area with the ground to help minimize compaction.

Finishing components

The 2430 offers different rear attachment options to meet the unique agronomic needs of each producer. Producers have a choice of two rear attachments on the 2430 Chisel Plow.

Knife-edge hydraulic rolling basket with internal basket scraper

Knife-edge rolling basket for the 2430 Chisel Plow

The knife-edge rolling basket for the 2430 Chisel Plow is made of hardened steel and handles rock strikes and adverse conditions well. The ease of down pressure adjustability allows the tool to adapt to changing field conditions. The internal basket scraper allows for a uniform field finish in wet conditions because baskets will not need to be raised out of the ground to avoid plugging; they can remain in the ground 100 percent of the time.

The John Deere 2430 Chisel Plow offers an active hydraulic rolling basket that gives the operator wide-ranging adjustability for a variety of conditions. The drawbars and rolling basket on the rear harrow are built with strength in mind for the demanding fall conditions. The system was designed to have the ability to run the rolling baskets in three different positions to finish and level the soil:

Raised: allows the operator to raise the rolling baskets in harsh, muddy conditions
Float: allows the operator to float the rolling baskets to lightly fluff soil
Apply down pressure: allows the operator to adjust the basket pressure to provide consistent contact with the ground, provides a firm seedbed, and shatters root balls

The hydraulic rolling basket is offered with the knife-edge basket which is the best for heavier, wet soil.

240 Coil-Tine Chisel Plow Harrow

The 240 Coil-Tine Chisel Plow Harrow is designed specifically for the 2430 Chisel Plows. Harrow performance has grown increasingly important over the last few years as soil profile finish and residue-handling capability are on the top of the list for producers. Both of these attributes are standouts on this heavy harrow.

Internal basket scraper

The internal basket scraper allows for a uniform field finish in wet conditions because the baskets will not need to be raised out of ground to avoid plugging and can stay in the ground 100 percent of the time.

Variety of models and sizes available

2430 Chisel Plow

The 2430 Chisel Plow is available in rigid and rigid fold, three-section folding, and five-section folding frame models.

Models	Type of fold	Standards
Rigid	Non-fold or horizontal fold	TruPosition™ or Tru-Depth
Flexible	Three-section over-center fold	TruPosition™ or Tru-Depth
Flexible	Five-section over-center fold	TruPosition

Rigid configurations
Working widths	Centerframe size	Transport width
3.35 m to 4.47 m (11 ft to 14 ft, 8 in.)	3.66 m (12 ft) non-folding	3.35 m to 4.9 m (11 ft to 16 ft)
4.3 m to 5.4 m (14 ft to 17 ft, 8 in.)	4.6 m (15 ft) non-folding
5.3 m to 6.4 m (17.5 ft to 21 ft)	3.66 m (12 ft) folding

Three-section configurations
Working widths	Centerframe size	Transport width
6.4 m to 7.5 m (21 ft to 24 ft, 7 in.)	3.05 m (10 ft)	4.8 m (15.3 ft)
7.6 m to 8.7 m (25 ft to 28 ft, 8 in.)
7.04 m to 7.8 m (23 ft, 1 in. to 25 ft, 9 in.)	3.66 m (12 ft)	5.5 m (17.58 ft)
8.2 m to 9.3 m (27 ft to 30 ft, 8 in.)
9.2 m to 10.3 m (30 ft, 4 in. to 33 ft, 8 in.)
10.7 m to 11.35 m (35 ft to 37 ft, 3 in.)
9.14 m to 9.9 m (30 ft to 32 ft, 3 in.)	4.6 m (15 ft)	6.375 m (20.58 ft)
10.4 m to 11.6 m (34 ft, 2 in. to 38 ft, 2 in.)
12.2 m to 12.9 m (40 ft to 42 ft, 3 in.)

Five-section configurations
Working widths	Centerframe size	Transport width
13.4 m to 14.2 m (44 ft to 46 ft, 8 in.)	3.66 m (12 ft)	5.3 m (17.25 ft)
14.2 m to 15.2 m (46 ft, 9 in. to 50 ft)
15.85 m to 16.7 m (52 ft to 54 ft, 8 in.)
14.3 m to 15.2 m (46 ft, 11 in. to 49 ft, 10 in.)	4.6 m (15 ft)	6.1 m (20 ft)
16.8 m to 17.6 m (55 ft to 57 ft, 10 in.)
18.3 m to 19.2 m (60 ft, 2 in. to 63 ft)

NOTE: Tru-Depth standards are available through 10 m (33 ft) only.

Excellent residue-handling capability

2430 Chisel Plow

The 2430 Chisel Plow has excellent residue-handling capability in primary tillage at all residue levels.

Typical percentages of residue cover remaining from the 2430 are listed in the following table. The percentages do not take into account variables such as the condition of the residue, speed, and soil type.

For machines with 305-mm (12-in.) spacing:

Starting residue cover (percent)	Remaining non-fragile* residue cover (percent)				Remaining fragile** residue cover (percent)
Starting residue cover (percent)	406-mm (16-in.) sweeps	51-mm x 356-mm (2-in. x 14-in.) chisel point	102-mm x 368-mm (4-in. x 14.5-in.) shovel	406-mm (16-in.) sweeps	51-mm x 356-mm (2-in. x 14-in.) chisel point	51-mm x 356-mm (2-in. x 14-in.) chisel point	406-mm (16-in.) sweeps	51-mm x 356-mm (2-in. x 14-in.) chisel point
100	80	70	100	80	70	100	80	70
90	72	65	90	72	65	90	72	65
80	65	56	80	65	56	80	65	56
70	55	50	70	55	50	70	55	50
60	50	42	60	50	42	60	50	42
50	40	35	50	40	35	50	40	35
40	32	28	40	32	28	40	32	28

*Non-fragile residue includes crops like corn, sorghum, wheat (more than 45 bu).

**Fragile residue includes crops like soybeans, edible beans, peas, wheat (less than 45 bu), sunflower, peanuts, and cotton.

For machines with 406-mm (16-in.) spacing:

Starting residue cover (percent)	Remaining non-fragile* residue cover (percent)				Remaining fragile** residue cover (percent)
Starting residue cover (percent)	457-mm (18-in.) sweeps	51-mm x 356-mm (2-in. x 14-in.) chisel point	102-mm x 368-mm (4-in. x 14.5-in.) shovel	76-mm x 610-mm (3-in. x 24-in.) shovel	457-mm (18-in.) sweeps	51-mm x 356-mm (2-in. x 14-in.) chisel point	102-mm x 368-mm (4-in. x 14.5-in.) shovel	76-mm x 610-mm (3-in. x 24-in.) shovel
100	83	73	63	63	55	50	45	45
90	75	68	58	58	50	45	40	40
80	68	59	53	53	45	40	35	35
70	58	53	45	45	38	35	30	30
60	53	45	38	38	33	30	27	27
50	43	38	33	33	27	25	22	22
40	35	31	28	28	22	20	18	18

*Non-fragile residue includes crops like corn, sorghum, and wheat (more than 45 bu).

**Fragile residue includes crops like soybeans, edible beans, peas, wheat (under 45 bu), sunflower, peanuts, and cotton.

Proven frame construction

3.4-m (11.17-ft) four-bar frame

Operators are requiring faster field working speeds, larger implements, and tractors because of a dramatic increase in farm size. The market is asking for and receiving tractors with more torque, more weight, and more horsepower.

Accommodating 600 engine horsepower tractors requires more from implement frame and hitch components, including thicker frame tubes, additional diagonal bracing, and frame gussets.

The frame is constructed of continuous 102-mm x 102-mm (4-in. x 4-in.) cross members inserted through 51-mm x 152-mm (2-in. x 6-in.), 76-mm x 152-mm (3-in. x 6-in.), and 102-mm x 152-mm (4-in. x 6-in.) fore-aft members. The mainframe boasts a structure made up of 102-mm x 152-mm (4-in. x 6-in.) fore-aft tubes.

The large frame member sizes, joint welds, and wheel module placement adds to the structural integrity, providing a stable front-to-rear and side-to-side operation.

Frame construction offers:

Consistent operating depth
Level operation
Restricts frame dip

Walk-Over wheels help provide consistent working depth

Walk-Over wheels

Walk-Over wheels provide a consistent working depth in uneven ground for level seedbeds and complete weed control.

The staggered wheel design provides extra room for residue flow, obstacles, and transport stability.

Wide variety of ground-engaging tools available

Shovels, chisels, and sweeps

A wide variety of tools such as sweeps, chisels, and twisted shovels are available for the operator to maintain surface residue and ground profile under varying weather and soil conditions.

Click here to explore more about points, chisels, and sweeps.
