Fill and rinse the M700(i) and R700i Trailed Sprayers using a closed transfer system. You can plug directly into the container with an adapter that is widely used by crop protection manufacturers.
Individual nozzle control provides efficient localized crop protection application. Save up to 5 percent in crop protection chemicals – up to 6 EUR per hectare*. The electronically controlled system reaches its ultimate potential when applied together with the PowrSpray™ system.
*NOTE: Based on a 500-ha wheat farm and assumed costs of 53€/ha for herbicides and 65€/ha for fungicides (5 percent x 118€ = 5,90€/ha).
Fill faster and spray more accurately with the unique dual-circuit PowrSpray system. It allows you to fill your sprayer in just 7 minutes (measured without priming) and gives you 98 percent* rate control accuracy.
The dual-circuit layout maximizes efficiency and ease of use. Each circuit is completely independent, featuring a dedicated centrifugal pump and is optimized for specific functions. Cross contamination between the two circuits is not possible, helping to reduce rinsing requirements and residual liquid disposal.
The filling circuit consists of the self-priming centrifugal filling pump (1) which fills the solution tank and provides clean water to the eductor. The filling circuit is not used during spraying and therefore not contaminated with chemicals and does not need to be rinsed.
Active Pause enables the operator to incorporate chemicals and rinse chemical containers with clean water without filling the solution tank.
The spraying circuit is equipped with a centrifugal spray pump which provides liquid to the spray boom and agitation. Only the spray circuit gets in contact with the chemicals and therefore is the only part of the machine which needs to be rinsed
Spraying pressure and application rate are controlled by adjusting the speed of the centrifugal spray pump via the load sense hydraulic pump drive. This load sense hydraulic drive enables a fast and accurate rate control.
*NOTE: The 98 percent accuracy figure is derived from JDLink™ data based on the John Deere piston diaphragm pump system compared to the John Deere 7.6-cm (3-in.) PowrSpray system and means that the set target rate is applied 98 percent of the time
Experience push-button filling, agitation, spraying, or rinsing on the R700i Trailed Sprayer. You have all the control you need either from the cab with the joystick or with the Solution Command system from the operator's station.
Product features are based on published information at the time of publication. Product features are subject to change without notice. Contact your local John Deere dealer for more information.
